GMX Ripper-X 110cc Junior Kids Quad Bike - Black/Red

Revolutionary Quad Bike Design with Multiple Safety Features

Experience a unique, fun and new perspective of riding a quad bike with this GMX Ripper-X.

Manufactured using the best quality materials and highest grade of workmanship. This four-stroke, 110cc quad bike can cruise up to speeds of 60km/hr depending on the terrain. It has been exclusively designed to suit riders of all proficiency levels. With special attention towards safety. The speed capabilities can be limited to suit a beginner or expert riders.  The bike has an electric start function with automatic transmission.

The unique steel frame design makes these Ripper quad bikes the strongest in the market. Features like physical kill switch, dead man's switch and remote kill switch offer multiple ways to ensure the safety of the rider. The bike comes almost 90% assembled, and it is recommended to get help from a qualified mechanic for assembly. The bike runs on petrol and can handle rider weights up to 90kg.

Features and Benefits

• 110cc four-stroke engine with electric start
• Automatic transmission and 60km/hr max. speed
• Deadman switch kills power when the rider moves away
• Remote kill switch to cut power from a distance
• Speed limiter device to set the max. speed
• Runs on unleaded petrol with 2.4l tank capacity
• Black and red colour accents
• Front safety grill to withstand impacts
• Strongest steel frame on the market

Specifications

• Maximum Speed: 60km/hr (depending on terrain surface)
• Seat Height: 570 mm
• Bore x Stroke: 52.4 mm x 49.5 mm
• Compression Ratio: 9.1: 1
• Front Tyre Blaze Type: 145/70-6 (6 inches)
• Rear Tyre Blaze Type: 145/70-6 (6 inches)
• Tyre Pressure: 68.0 ± 0.2 kPa
• Wheelbase: 855mm
• Handlebar: High Bend Mini-Bar
• Handlebar Grips: Soft High Grip Rubber
• Magneto Type: Electronic Ignition System
• Ground Clearance: 80 mm
• Swing arm: Steel
• Fuel Capacity: 2.4 L
• Triple Clamps: Steel
• Engine Oil Grade: Non-Synthetic 15W/40-SE - 4 Stroke Engine Oil
• Optimal Engine Oil Level: 800 ML
• Intake / Exhaust: Race Pipe + Performance Steel Muffler
• Charger: Included

Technical

• Engine Model: 152 FMH/ 110 cc GMX Series 1 Engine
• Engine Type: 4 Stroke - Single Cylinder - Air Cooled
• Starting Mode: Electric Start
• Ignition Type: CDI
• Chain: 428#76
• Clutch Type: Heavy Duty Wet Multi Plate
• Cylinder ratio: 107 ML
• Transmission: Automatic
• Fuel: Regular Unleaded (92 or higher)
• Fuel Delivery System: PZ19 Carburetor
• Drive: 428 # 76 Chain
• Front Brake: Front Drum Brakes
• Rear Brake: Rear Hydraulic Disc Brakes
• Gearing: 14 Tooth Front / 37 Tooth Rear
• Idle Speed: ≤800 ppm
• Maximum Output: KW / HP : 8HP
• Maximum Power: 5.5 Kw/8000 (r/min)
• Maximum Torque: 7.2 N.m/ 5500 (r/min)
• Rated Loading Capacity: 90 Kgs
• Rider Capacity: 1 Person
• Product Size: 1190 x 760 x 820 mm
• Product Weight: 65kg
• Packaging Dimensions: 1140 x670 x640 mm

Assembly Instructions

• Assembly Products are up to 90% assembled. Minor assembly is required and in the interest of safety, it is recommended that you have the quad bike assembled by a qualified, skilled small engine mechanic.
• You may need to provide proof of being assembled by a skilled mechanic, if not a report from a small engine mechanic advising the issues to process you warranty claims.
• Labour is not covered under warranty. Warranty is a parts replacement warranty and does not cover labour costs.
• Defective parts may need to be sent back to us for inspection. Before using the product, check that all nuts, wiring and bolts are tightened as they can become loose during shipping.
• For the first tank, run in the engine, please do not over-rev the engine for the first 1-3 months as the engine is new and should be treated as such. This item is intended for off-road use only.

Important Safety & Product Information

• Always wear a helmet, product clothing and gear such as goggles, long sleeves, long pants, boots and gloves/hand protection when riding these products.
• For motorised products, a motorbike standard helmet needs to be worn.
• Never let children ride quad bikes that are meant for adults, even as passengers. Do not carry any passengers on quad bikes that are meant for one person.
• Quad bikes are not all-terrain vehicles so they cannot go safely on all types of terrain.
• Avoid riding on rough terrain or steep slopes. Ride on familiar tracks and beware of obstacles.
• Never ride under the influence of alcohol/drugs. Ensure children are supervised at all times near any quad bike activity.
• Always carry a mobile phone or radio device so you can contact help in case of an emergency.
• Always adhere to the maximum load of the product.
